Overview

Canon EOS 77D DSLR Camera Features:

24.2MP APS-C CMOS Sensor

The Canon 77D incorporates a 24.2MP APS-C crop CMOS sensor. The sensor is capable of capturing crystal clear images with accurate colours and low levels of noise. The large megapixel count also enables ample cropping.

DIGIC 7 image processor

The EOS 77D incorporates Canon's latest DIGIC 7 image processor. The processor actively reduces noise, corrects colours and lens anomalies, and provides enough processing power to the body to shoot Full HD at 50p or continuous shooting at up 6fps.

ISO 100-51200

The sensor and DIGIC 7 processor provides the 77D with an excellent standard light sensitivity range of ISO 100-25600 and an extended ISO of 51200. The wide ISO range and fast Canon lenses available will enable users to shoot flash-free in almost any lighting condition.

Full HD 1080p Video Recording at 50 FPS

The Canon EOS 77D can record Full HD video internally at up to 50 frames per second in a high quality hight bit-rate mp4 format, or in MOV format with AlI-I compression at up to 30 fps. Videographers can also enjoy full control over audio levels and capture professional quality sound thanks to a microphone input.

45-Point All Cross-Type autofocus

The camera features a new high-performance, flexible 45 point all cross-type AF system. When used with a compatible lens, each focus point is an f/5.6 cross-type, which ensures the camera can lock on to both horizontal and vertical detail quickly and precisely . The technology delivers accurate, fast autofocus and tracking over a wide area and across a range of subjects. Designed to shoot in a range of lighting conditions, with a variety of lens and extender combinations, the AF system is sensitive down to -3EV (moonlight ). It contains 27 f/8 compatible AF points (9 f/8 cross-type) and one extra sensitive f/2.8 and f/5.6 dual cross-type point in the centre.

Dual Pixel CMOS AF

The 77D features Dual Pixel CMOS AF that is enhanced thanks to the improved sensor performance and revised AF algorithms in the camera. When shooting or recording in live view, the Dual Pixel CMOS AF system integrates two separate photodiodes within each pixel to provide a dense array of phase-detect points across the image sensor for fast and accurate focus. Dual Pixel CMOS AF is now also possible with all EF and EF-S lenses and can be used in combination with continuous shooting during Live View.

5-axis electronic video image stabilisation

5-axis Movie Electronic IS helps to minimize video shake and blur in the horizontal, vertical, and rotational planes, even when recording Full HD videos. This effectively reduces most unwanted high frequency movements that would have spoiled your video.

Pop-up flash with Integrated Speedlite Transmitter

The 77D incorporates a pop-up flash for decent light fill. The pop-up flash features an integrated Speedlite Transmitter that will enable you to trigger other supported off-camera speedlites/flashguns, giving you more creative freedom.

Swivel & Tilt 3 inch touchscreen LCD

The Canon EOS 77D features a 3 inch LCD screen with tilt and touch functionality. By swivelling and/or tilting the screen users will easily be able to compose and take pictures/videos from high/low angles as well as move the LCD to a front facing direction. The touch screen functionality will enable easy menu navigation, media playback and focus selection.

Built-In Wi-Fi with NFC

Users can connect to the camera’s own wireless hotspot by using either using the supplied EOS Utility software or the downloadable Canon Camera Connect App. When connected user will be able to get a live view, trigger the camera, and effortlessly transfer MP4's and JPEGs.

Canon EF-S 18-55mm f/4-5.6 IS STM Lens

The new Canon EF-S 18-55mm f/4-5.6 IS STM is a compact zoom lens that provides basic reach for common subjects. The new lens is even smaller and lighter than than the older f/3.5-5.6, making it a great lens to bring with you on your everyday travels. The lead screw-type stepping motor (STM) helps ensure smooth autofocus and near-silent operation, helping you capture videos with great audio and minimal background noise so you won't distract your subject in a quiet photo environment. Advanced image stabilization greatly helps to reduce blur in handheld shots

Canon EF-S 18-135mm f/3.5-5.6 IS Nano USM Lens

The Canon EF-S 18-135mm f/3.5-5.6 IS Nano USM is a versatile zoom lens that is suitable for both still and video applications. The lens features a unique Nano USM autofocus system, which combines ring-type USM and STM focusing mechanisms to provide the focusing speed and accuracy required by photographers and the smoothness and quietness required by videographers.

Specification

Image Sensor	22.3mm x 14.9 mm CMOS
Effective Pixels	Approx. 24.20 megapixels
Total Pixels	Approx. 25.80 megapixels
Aspect Ratio	3:2
Low-Pass Filter	Built-in/Fixed
Sensor Cleaning	EOS integrated cleaning system
Colour Filter Type	Primary Colour
Image Processor	DIGIC 7
Lens Mount	EF/EF-S
Focal Length	Equivalent to 1.6x the focal length of the lens

Image Stabilisation	Optical Image Stabilizer on compatible lens Movie: In-camera 5-axis Digital IS available. Further stabilisation enhancements from lenses compatible with Dynamic IS
Focusing	Via optical viewfinder: TTL-CT-SIR with a CMOS sensor Via liveview on LCD screen: Dual Pixel CMOS AF System.  Phase detection pixels built onto imaging sensor
AF System/ Points	Via optical viewfinder: 45 cross-type AF points (45 f/5.6 cross-type AF points, 27 f/8 points (9 cross-type),  centre point is f/2.8 and f/5.6 dual cross-type)  Via liveview on LCD screen: Maximum 49 AF points (Fixed location on 7x7 grid) via camera automatic selection Freely position 1 AF point/ 1 AF Zone (9 points, 3x3 grid) via manual selection
AF working range	Via optical viewfinder: EV -3 - 18 (at 23 °C & ISO 100) with centre AF point & f/2.8 or brighter lenses Via liveview on LCD screen: EV -2 - 18 (at 23 °C & ISO 100) with One-Shot AF
AF Modes	AI Focus One Shot AI Servo (AI Servo II algorithm)
AF Point Selection	Via optical viewfinder: Automatic selection: 45 point AF Manual selection: Single point AF Manual selection: Zone AF Manual selection: Large Zone AF
AF Lock	Locked when shutter button is pressed half way in One Shot AF mode or AF-ON Button is pressed.
AF Assist Beam	Intermittent firing of built-in flash (effective range up to 4.0 m) or emitted by optional dedicated Speedlite
Metering modes	Via optical viewfinder: 7560-pixel RGB+IR metering sensor Metering with the area divided into 63 segments (9 × 7) (1) Evaluative metering (linked to all AF points) (2) Partial metering (approx. 6.0 % of viewfinder) (3) Spot metering (approx. 3.5 % of viewfinder) (4) Center-weighted average metering Via liveview on LCD screen: (1) Evaluative metering (315 zones) (2) Partial metering (approx. 6.0 % of LCD screen) (3) Spot metering (approx. 2.6 % of LCD screen) (4) Center-weighted average metering
Exposure Compensation	+/-5 EV in 1/3 or 1/2 stop increments (can be combined with AEB).

ISO Sensitivity	Auto (100-25600), 100-25600 (in 1/3-stop or whole stop increments) ISO can be expanded to H: 51200 During Movie shooting: Auto (100-12800), 100-12800 (in 1/3-stop or whole stop increments) ISO can be expanded to H: 25600
Shutter	Electronically-controlled focal-plane shutter
Speed	30-1/4000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode)
White Balance	Automatic white balance with the imaging sensor
Settings	AWB (Ambience priority, White priority), Daylight, Shade, Cloudy, Tungsten light, White Fluorescent light, Flash, Custom, Colour Temperature Setting. White balance compensation: 1. Blue/Amber bias +/-9 levels 2. Magenta/ Green bias +/-9 levels
WB Bracketing	+/-3 levels in single level increments 3 bracketed images per shutter release. Selectable Blue/Amber bias or Magenta/ Green bias.
Coverage (Vertical/Horizontal)	Approx. 95 %
Magnification	Approx. 0.82x
Eyepoint	Approx. 19 mm (from eyepiece lens centre)

In the Box

• Canon EOS 77D DSLR Camera (Body Only)
• 18-55mm f/4-5.6 IS STM Lens
• LP-E17 Lithium-Ion Battery
• LC-E17 Charger
• Eyecup
• Body Cap
• Camera Strap



Overview

One of the most versatile focal lengths available, the EF 50mm f/1.8 STM Lens from Canon pairs this classic lens design with enhancements to the AF system and physical design that make it both faster and smaller. Utilizing an STM stepping motor, this lens is ideal for both still and video shooting due to its speedy and smooth operation.

Further benefitting video shooters, the STM motor also supports the Movie Servo AF mode on select DSLRs for precise and near-silent focusing. An updated exterior design includes a metal lens mount and a re-located focusing ring in order to accommodate the compact overall form factor. The 50mm f/1.8 is a classic, tested lens design, and thanks to enhanced autofocus and a svelte profile, this lens is ideal for everyday shooting in a wide variety of conditions.

The optical design of this lens incorporates optimized coatings that help to reduce flare and ghosting for increased contrast and color neutrality. The f/1.8 maximum aperture is effective for low-light shooting as well as for controlling your focus plane for selective focus shooting. Seven rounded diaphragm blades further enhance the look of out of focus regions in an image, making it well-suited to portraiture and creative environmental shooting.

Standard prime 50mm lens is designed for use on full-frame EOS DSLR, however can also be used with APS-C-sized sensors where it will provide an 80mm equivalent focal length.

Fast f/1.8 maximum aperture benefits working in low-light conditions and also enables precise control over the focus plane when working with selective focus techniques. Seven rounded diaphragm blades further contribute to a pleasing out of focus quality with shallow depth of field imagery.

A gear-type STM stepping motor is incorporated into the lens' design to provide quick, smooth, and near silent autofocus performance. Additionally, this focusing mechanism also pairs well with EOS cameras featuring the Move Servo AF mode to enable continuous focusing performance when working in live view.

Full-time manual focus override is available for fine-tuning your focus position for selective focus applications.

Optimized lens coatings help to suppress lens flare and ghosting for increased contrast and more color-neutral imagery.

An enhanced exterior design features a metal lens mount for durability as well as a re-located focusing ring to maintain a compact 2.7 x 1.5" form factor.

Specifications

PERFORMANCE
Focal length	50mm
Aperture	Maximum: f/1.8
Camera Mount Type	Canon EF
Format Compatibility	35mm Film / Full-Frame Digital Sensor Canon (APS-C)
Angle of View	14" (35.56 cm)
Minimum Focus Distance	0.21x
Magnification	0.15x
Maximum Reproduction Ratio	1:7
Elements/Groups	6/5
Diaphragm Blades	7, Rounded
-	-
FEATURES
Image Stabilization	no
autofocus	Yes
Tripod collar	no
-	-
PHYSICAL
Filter thread	Front:49 mm
Dimension (dxl)	Approx. 2.7 x 1.6" (68.58 x 40.64 mm
weight	5.7 oz (162 g)
-	-
PACKAFING INFO
Package weight	0.65 lb
Box dimension(LxWxH)	4.4 x 4.3 x 4.0"

In the Box

• Canon EF 50mm f/1.8 STM Lens
• Front lens cap
• Rear lens cap

Overview

Canon EOS 77D DSLR Camera Features:

24.2MP APS-C CMOS Sensor

The Canon 77D incorporates a 24.2MP APS-C crop CMOS sensor. The sensor is capable of capturing crystal clear images with accurate colours and low levels of noise. The large megapixel count also enables ample cropping.

DIGIC 7 image processor

The EOS 77D incorporates Canon's latest DIGIC 7 image processor. The processor actively reduces noise, corrects colours and lens anomalies, and provides enough processing power to the body to shoot Full HD at 50p or continuous shooting at up 6fps.

ISO 100-51200

The sensor and DIGIC 7 processor provides the 77D with an excellent standard light sensitivity range of ISO 100-25600 and an extended ISO of 51200. The wide ISO range and fast Canon lenses available will enable users to shoot flash-free in almost any lighting condition.

Full HD 1080p Video Recording at 50 FPS

The Canon EOS 77D can record Full HD video internally at up to 50 frames per second in a high quality hight bit-rate mp4 format, or in MOV format with AlI-I compression at up to 30 fps. Videographers can also enjoy full control over audio levels and capture professional quality sound thanks to a microphone input.

45-Point All Cross-Type autofocus

The camera features a new high-performance, flexible 45 point all cross-type AF system. When used with a compatible lens, each focus point is an f/5.6 cross-type, which ensures the camera can lock on to both horizontal and vertical detail quickly and precisely . The technology delivers accurate, fast autofocus and tracking over a wide area and across a range of subjects. Designed to shoot in a range of lighting conditions, with a variety of lens and extender combinations, the AF system is sensitive down to -3EV (moonlight ). It contains 27 f/8 compatible AF points (9 f/8 cross-type) and one extra sensitive f/2.8 and f/5.6 dual cross-type point in the centre.

Dual Pixel CMOS AF

The 77D features Dual Pixel CMOS AF that is enhanced thanks to the improved sensor performance and revised AF algorithms in the camera. When shooting or recording in live view, the Dual Pixel CMOS AF system integrates two separate photodiodes within each pixel to provide a dense array of phase-detect points across the image sensor for fast and accurate focus. Dual Pixel CMOS AF is now also possible with all EF and EF-S lenses and can be used in combination with continuous shooting during Live View.

5-axis electronic video image stabilisation

5-axis Movie Electronic IS helps to minimize video shake and blur in the horizontal, vertical, and rotational planes, even when recording Full HD videos. This effectively reduces most unwanted high frequency movements that would have spoiled your video.

Pop-up flash with Integrated Speedlite Transmitter

The 77D incorporates a pop-up flash for decent light fill. The pop-up flash features an integrated Speedlite Transmitter that will enable you to trigger other supported off-camera speedlites/flashguns, giving you more creative freedom.

Swivel & Tilt 3 inch touchscreen LCD

The Canon EOS 77D features a 3 inch LCD screen with tilt and touch functionality. By swivelling and/or tilting the screen users will easily be able to compose and take pictures/videos from high/low angles as well as move the LCD to a front facing direction. The touch screen functionality will enable easy menu navigation, media playback and focus selection.

Built-In Wi-Fi with NFC

Users can connect to the camera’s own wireless hotspot by using either using the supplied EOS Utility software or the downloadable Canon Camera Connect App. When connected user will be able to get a live view, trigger the camera, and effortlessly transfer MP4's and JPEGs.

Canon EF-S 18-55mm f/4-5.6 IS STM Lens

The new Canon EF-S 18-55mm f/4-5.6 IS STM is a compact zoom lens that provides basic reach for common subjects. The new lens is even smaller and lighter than than the older f/3.5-5.6, making it a great lens to bring with you on your everyday travels. The lead screw-type stepping motor (STM) helps ensure smooth autofocus and near-silent operation, helping you capture videos with great audio and minimal background noise so you won't distract your subject in a quiet photo environment. Advanced image stabilization greatly helps to reduce blur in handheld shots

Specification

Image Sensor	22.3mm x 14.9 mm CMOS
Effective Pixels	Approx. 24.20 megapixels
Total Pixels	Approx. 25.80 megapixels
Aspect Ratio	3:2
Low-Pass Filter	Built-in/Fixed
Sensor Cleaning	EOS integrated cleaning system
Colour Filter Type	Primary Colour
Image Processor	DIGIC 7
Lens Mount	EF/EF-S
Focal Length	Equivalent to 1.6x the focal length of the lens

Image Stabilisation	Optical Image Stabilizer on compatible lens Movie: In-camera 5-axis Digital IS available. Further stabilisation enhancements from lenses compatible with Dynamic IS
Focusing	Via optical viewfinder: TTL-CT-SIR with a CMOS sensor Via liveview on LCD screen: Dual Pixel CMOS AF System.  Phase detection pixels built onto imaging sensor
AF System/ Points	Via optical viewfinder: 45 cross-type AF points (45 f/5.6 cross-type AF points, 27 f/8 points (9 cross-type),  centre point is f/2.8 and f/5.6 dual cross-type)  Via liveview on LCD screen: Maximum 49 AF points (Fixed location on 7x7 grid) via camera automatic selection Freely position 1 AF point/ 1 AF Zone (9 points, 3x3 grid) via manual selection
AF working range	Via optical viewfinder: EV -3 - 18 (at 23 °C & ISO 100) with centre AF point & f/2.8 or brighter lenses Via liveview on LCD screen: EV -2 - 18 (at 23 °C & ISO 100) with One-Shot AF
AF Modes	AI Focus One Shot AI Servo (AI Servo II algorithm)
AF Point Selection	Via optical viewfinder: Automatic selection: 45 point AF Manual selection: Single point AF Manual selection: Zone AF Manual selection: Large Zone AF
AF Lock	Locked when shutter button is pressed half way in One Shot AF mode or AF-ON Button is pressed.
AF Assist Beam	Intermittent firing of built-in flash (effective range up to 4.0 m) or emitted by optional dedicated Speedlite
Metering modes	Via optical viewfinder: 7560-pixel RGB+IR metering sensor Metering with the area divided into 63 segments (9 × 7) (1) Evaluative metering (linked to all AF points) (2) Partial metering (approx. 6.0 % of viewfinder) (3) Spot metering (approx. 3.5 % of viewfinder) (4) Center-weighted average metering Via liveview on LCD screen: (1) Evaluative metering (315 zones) (2) Partial metering (approx. 6.0 % of LCD screen) (3) Spot metering (approx. 2.6 % of LCD screen) (4) Center-weighted average metering
Exposure Compensation	+/-5 EV in 1/3 or 1/2 stop increments (can be combined with AEB).

ISO Sensitivity	Auto (100-25600), 100-25600 (in 1/3-stop or whole stop increments) ISO can be expanded to H: 51200 During Movie shooting: Auto (100-12800), 100-12800 (in 1/3-stop or whole stop increments) ISO can be expanded to H: 25600
Shutter	Electronically-controlled focal-plane shutter
Speed	30-1/4000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode)
White Balance	Automatic white balance with the imaging sensor
Settings	AWB (Ambience priority, White priority), Daylight, Shade, Cloudy, Tungsten light, White Fluorescent light, Flash, Custom, Colour Temperature Setting. White balance compensation: 1. Blue/Amber bias +/-9 levels 2. Magenta/ Green bias +/-9 levels
WB Bracketing	+/-3 levels in single level increments 3 bracketed images per shutter release. Selectable Blue/Amber bias or Magenta/ Green bias.
Coverage (Vertical/Horizontal)	Approx. 95 %
Magnification	Approx. 0.82x
Eyepoint	Approx. 19 mm (from eyepiece lens centre)

In the Box

• Canon EOS 77D DSLR Camera (Body Only)
• 18-55mm f/4-5.6 IS STM Lens
• LP-E17 Lithium-Ion Battery
• LC-E17 Charger
• Eyecup
• Body Cap
• Camera Strap



Overview

This EF 50mm f/1.4 USM Lens from Canon is a standard length lens featuring superb quality and portability. Its f/1.4 maximum aperture makes it very effective in low light situations and able to provide shallow depth of field focus. Two high-refraction lens elements and new Gaussian optics eliminate astigmatism and suppress astigmatic difference. Its ultrasonic autofocus motor (USM) enables fast, smooth and silent autofocus action and full-time manual focus override allows for the precision of manual focus even in One Shot AF mode.

Standard focal length 50mm lens is effective in a multitude of shooting situations and ideal for day-to-day shooting.

An f/1.4 maximum aperture provides clear imaging in low light situations and shallow depth of field.

Ultrasonic autofocus motor (USM) operation is fast, smooth and virtually silent.

Specifications

PERFORMANCE
Focal length	50mm
Aperture	Maximum: f/1.4 Minimum: f/22
Camera Mount Type	Canon EF
Format Compatibility	35mm Film / Full-Frame Digital Sensor Canon (APS-C)
Angle of View	46°
Minimum Focus Distance	1.5' (45 cm)
Magnification	0.15x
Maximum Reproduction Ratio	1:7
Elements/Groups	7/6
Diaphragm Blades	8
-	-
FEATURES
Image Stabilization	no
autofocus	Yes
Tripod collar	no
-	-
PHYSICAL
Filter thread	Front:58 mm
Dimension (dxl)	Approx. 2.9 x 2.0" (7.37 x 5.08 cm)
weight	10.23 oz (290 g)
-	-
PACKAGING INFO
Package weight	0.85 lb
Box dimension(LxWxH)	4.6 x 4.3 x 4.1"

In the Box

• Canon EF 50mm f/1.4 USM Lens
• 58mm Snap-On Lens Cap
• Lens Dust Cap E (Rear)
