1" Exmor R CMOS Sensor

The HXR-NX100 incorporates a 1.0-type Exmor R CMOS sensor with 14.2 million effective pixels, which is approximately the same size as Super16mm film frame. The R designation signifies that this is a backside illuminated sensor, which places the circuitry behind the photosites, allowing more light to reach the sensors and resulting in greater low light sensitivity.

Depth of Field

The 1.0-type offers more shallow depth of field than 1/2.88-type or smaller sensors.

Sony G Lens with 12x Optical Zoom, 24x Clear Image Zoom

The HXR-NX100 is supplied with a fixed 12x 29mm wide-angle Sony G lens. The 12x optical zoom can be doubled to 24x with Clear Image Zoom, and the Digital Extender function can double this range again, up to 48x zoom.

Frame Rate Flexibility

The camcorder records using the AVCHD 2.0 codec for Full HD 1920x1080 resolution video at frame rates of 24p, 30p, 60i, and 60p. The camcorder also offers 720/60p AVCHD capture, 2x slow motion and 60x quick motion recording, as well as standard definition DV recording. The two SD card slots enable simultaneous or relay recording.

Lens Control

The three lens rings enables smooth, natural adjustment of focusing, zooming, and iris control. It can also be used in full-auto mode or completely manual for maximum creative control.

Built-In Filters

The HXR-NX100 is equipped with a ND Filter function, allowing you to choose four conventional mechanical ND filter positions (Clear, 1/4ND, 1/16ND and 1/64ND) for better exposure and depth of field control).

Media Slots

The HXR-NX100 is equipped with two memory card slots, one of which is for SDHC/SDXC cards only, while the other slot is compatible with SDHC/SDXC and Memory Stick PRO Duo (Mark 2)/Memory Stick PRO-HG Duo cards. Two media slots can be used to record in either "SIMUL" or "RELAY" mode. "SIMUL" mode permits simultaneous recording to two memory cards, while "RELAY" mode automatically switches recording from the first to the second memory card when the first is full.

You can set up the two Start/Stop buttons on the HXR-NX100, one on the grip and one on the camcorder body, to independently start and stop recording on different memory cards while recording in "SIMUL" mode.

Multi-Interface Shoe

The MI Shoe expands your options to use accessories without cables, such as optional HVL-LBPC Video Light or the UWP-D wireless microphone series.

EVF and LCD Viewfinder

The HXR-NX100 incorporates a 0.24-type 1550K dots EVF and 3.5-type 1550K dots LCD.

Multi-Format Recording

The HXR-NX100 records AVCHD and DV, which are suitable for conventional workflow, and newly implemented XAVC S 50Mbps, which realizes better image quality.

Picture Profiles

You can fine-tune the look of movies before shooting by adjusting up to 99 parameters such as gamma, knee, black level, color model/level/phase and more. Adjusted parameters can be saved along with other settings as a profile, and up to six profiles can be stored for later recall.

You can copy the settings from one HXR-NX100 to another HXR-NX100 so that user can shoot with multiple cameras in the same settings. The picture profiles only work with the same model of camera.

Wide 26.8mm Angle Lens

With 12x zoom, the lens features a 26.8mm equivalent focal length when at its widest setting, helping to minimize the times a wide angle adapter or converter will be required

Exmor R CMOS sensor

The Exmor R CMOS has been redesigned from the previous model to deliver up to 0.8 lux sensitivity in SD mode. In part this sensitivity bump comes from the use of backside illumination, which moves much of the circuity to the back of the sensor enabling larger photosites which can capture more light

OLED Tru-Finder and 3" LCD Panel

The Tru-Finder viewfinder uses OLED technology for a better viewing angle and features a resolution of 1.44 million dots, adequate for critical manual focusing. There is also a 3" LCD panel for when the camera is not being used over the shoulder, which features a 0.92 million dot resolution. The LCD screen can be close or disabled when not in use to conserve battery

Low-Light Shooting

The HXR-MC2500 is capable of up to 0.8 lux minimum illumination when using manual settings with the shutter set to 1/15 second, the iris at f/1.8, and the gain at 33dB. Plus, there is a built-in LED video light that casts 800 lumens brightness when 1.6' from the subject

Wi-Fi Enabled with NFC Connectivity

Through Wi-Fi it is possible to operate a number of camera settings from a smartphone or tablet. You can also monitor a live feed, which is ideal for setups - such as a news conference - where the camera will be placed somewhere that people aren't allowed during the event. The NFC feature saves time, allowing you to pair the camera with NFC-enabled mobile devices simply by tapping the device to the camera. Functions you can access through the app include:

• Record start/stop
• Zoom
• Iris
• Touch Auto Focus

Hybrid Recording

The camera comes equipped with 32GB of built-in memory, offering approximately 170 minutes in the 24 Mbps (FX) quality setting. There is also a memory card slot that can accept SD, SDHC, SDXC, and Sony Memory Stick Pro Duo cards - all available separately - for even longer recording times. Simultaneous modes lets you record to both media at once, while Relay will roller over from one media to the other once the fist fills up. Relay makes indefinite recording possible, as long as the battery lasts or AC power is available

Multi-Interface (MI) Shoe

In addition to the two standard cold shoes, the proprietary Multi-Interface shoe allows the camera to talk directly to a range of accessories from Sony without requiring separate wiring. Compatible accessories include microphones, wireless receivers, and even flashes

Note: Multi-Interface shoe is not compatible with accessories that use the earlier Active Interface (AIS) shoe

DV Recording

In SD mode, the HXR-MC2500 records in DV codec - the same format used by MiniDV tape cameras - and puts the file in an AVI wrapper. This format is supported by most editing programs, and features less compression than the MPEG-2 SD mode found on many other cameras

Assignable Lens Ring

The lens ring can be set to manually control focus, exposure, white balance, iris, or shutter speed - giving you direct access without having to go through the camera's menu

Time Code

It is possible to set SMPTE timecode or user bit (UB) for multi camera productions or to make it easier to locate footage in post

BNC Composite Output

The composite output uses a BNC terminal, which is a locking connector that reduces the risk of accidentally yanking the cable out during a live broadcast

Optical SteadyShot Image Stabilization with Active Mode

In addition to normal optical image stabilization, Active Mode provides compensation for the sway that occurs while waking

Quick AF System

Designed to improve auto focus accuracy even in low-light conditions

L Series Battery

Support for Sony's professional L Series battery line means up to 14 hours of battery life is possible when using the separately available NPF-970 battery
