Overview

Suitable for portraits, head shots, interviews, and fashion, the 34.8″ Light Dome II from Aputure is a 16-sided modifier that offers quality of light options and wide compatibility with Aputure lights, as well as those of the many other manufacturers that use the popular Bowens front accessory mount. The structure of the Light Dome II is fortified by its 16 durable steel support rods, while its silver interior maximizes your light source’s output. Its 24″ depth produces a focused light with directional control that can be narrowed further for selective lighting with the included 40 fabric grid. Aputure provides a removable inner diffuser and both 1.5-stop and 2.5-stop front diffusers that you can use individually or all at once for softness and contrast options. The supplied gel filter holder also offers creative color options. Any way you use it, you’ll find that the Light Dome II renders soft, flattering light with a wraparound quality and produces round, natural-looking catchlights in the eyes of your subject.

Overview

This is a chrome-plated 10.75' Avenger C-Stand Grip Arm Kit . The Century "C" Stand is a favorite among professional photographers, film makers and videographers everywhere. It is durable, and designed to collapse flat for easy transport and storage.

The leg design provides a very low center of gravity, and makes it easy to bury in the soil or sand, or accept sandbags for extra stability.

This kit includes a 2.5" swivel grip and a 40" grip arm, which is suitable for holding reflectors, or a lightweight light head. It has a chrome-plated finish.

Fold Away Legs

Fold-away, spring loaded legs with unique mounts which are easy to replace.

Durable Finish

Resists all weather conditions.

Innovative Design

The base allows individual legs to be set at any angle, and can be positioned in locations not possible with classic stands.

Captive Handles

"T" shaped handles are "captive" and do not come off the stand when unscrewed, preventing loss.

Specifications

Model	A2033FKIT
Maximum Height	10.75' (3.26m)
Minimum Height	4.4' (1.34 m)
Closed Length	4.4' (1.34 m)
Footprint Diameter	37.4" (94cm)
Weight	12.1 lb (5.5kg)
Maximum Load	22 lb (10kg)
Attachment Size	5/8" male stud
Accepts Wheels	No
Air Cushioned	No

Overview

Faster Video Production Plus Live Streaming

Live production is the fastest way to complete a finished program, plus you can stream it to a live global audience via YouTube at the same time. The USB webcam output of ATEM Mini connects to any computer and looks just like a built in webcam so all streaming software for social media platforms work. With up to 4 HDMI inputs you can set up multiple camera angles such as wide shots along with independent close ups of each person in the performance. Or you can connect to a computer with a PowerPoint slide show, video clip playback, web sites or gaming consoles. All switching is in real time so you can live stream to any social media platform such as YouTube, Facebook, TwitchTV and many more.



Self Contained Broadcast Quality Switcher

ATEM Mini features a compact control panel based design with all video, audio and control connections on the rear panel. The front panel includes easy to use buttons for selecting sources, adjusting audio inputs, as well as selecting video effects and transitions. The rear panel includes HDMI inputs for connecting cameras or computers, plus additional microphone inputs. The ATEM Mini program is output via an HDMI video out as well as a USB for webcam output. The front panel buttons are large and easy to use by feel, so it’s even possible to use the switcher while presenting. You also get audio mixer buttons for live audio mixing. The fade to black button "FTB" lets you fade down at the end of your program.



Easy to Use and Fast to Learn

ATEM Mini is very easy to use, as you simply press any of the input buttons labelled 1 to 4 on the front panel to change or cut between video sources. You can choose between cut transitions or effects transitions by selecting the cut or auto buttons on the panel. Unlike cut, the auto button tells ATEM Mini to use a selected video effect when switching between inputs. You can select from exciting transitions such as a commonly used dissolve, or more dramatic effects such as dip to color, DVE squeeze and DVE push. The DVE is perfect for picture in picture effects and you can instantly set up different picture positions from the buttons on the control panel. There is even a still store for titles and graphics accessible via external software control.



Stream Live Interviews

ATEM Mini is perfect for interviews as you can connect multiple cameras for close ups of the host, interviewee and wide shots, plus ATEM Mini is so small the host can even switch in small studios. You can record via the HDMI output or live stream using Open Broadcaster software.



Connect up to 4 Independent Cameras

With 4 independent HDMI inputs, you can connect up to 4 high quality consumer video cameras. Video cameras with HDMI outputs are dramatically better quality than simple webcam cameras as they use higher quality lenses plus have much better low light sensitivity. All connected sources will re‑sync to the switcher if they operate at different video standards, which means all inputs just work and you can handle unknown equipment if you are visiting new venues or locations. Because cameras with HDMI often support interchangeable lenses, you can change to wide angles lenses for wide shots and zoom lenses for close ups. Imagine using the low light capability of professional cameras for theater production and music videos.



Outputs to HDMI Video and USB Webcam

To ensure the maximum compatibility possible, ATEM Mini features a USB connection that operates as a simple webcam source. That means you can plug in and instantly get working with any video software. The software is tricked into thinking the ATEM Mini is a common webcam, but it's really a live production switcher. That guarantees full compatibility with all software in full resolution 1080HD quality. Choose any software you like, such as Open Broadcaster for live streaming, or Skype for point to point presentations. ATEM Mini works with software and platforms such as Open Broadcaster, XSplit Broadcaster, YouTube Live, Facebook Live, Skype, Twitch TV, Periscope, Livestream, Wirecast and more.



Add Exciting Video Effects

One of the benefits of ATEM Mini is the professional production values that are possible using the range of built in video effects. The cut button ensures an instant cut when switching between sources. The auto button is a professional term that's used on large broadcast switchers to enable video effects transitions. There are also duration buttons for video effects allowing 0.5, 1, 1.5 and 2 second settings. You can also select the type of effect you want including fade which does a smooth transition between sources and dip which fades via a color during the transition. Or use fun DVE effects that move the image off screen when transitioning between sources.



Record to Video for YouTube Uploads

The HDMI program output is perfect for connecting ATEM Mini into an external recorder or monitor. Supports recorders such as the HyperDeck Studio Mini and Blackmagic Video Assist. You get a high quality output with switcher program video, plus live audio from the internal audio mixer. The HDMI output can even be connected to video projectors in large venues. If you connect the ATEM Software Panel you can even change the HDMI output direct from any of the video inputs. There's also a low latency setting allowing output of connected gaming consoles on the HDMI output. If you enable broadcast style mix effects switching, the HDMI output can be used to preview sources before a transition.



Work with Professional Microphones

With two independent 3.5mm stereo audio inputs, you can connect desktop and lapel microphones. You can even connect a music player to generate introduction music after the live stream commences but before the program starts. With 2 extra stereo audio inputs, you can ensure a host and the guest both have lapel microphones when doing interviews. All audio inputs to ATEM Mini include buttons on the panel for adjusting audio level and enabling inputs into the audio mixer. ATEM Mini features a full Fairlight audio mixer and all HDMI audio inputs and both microphone inputs are all connected separately to the audio mixer so you can live mix from all audio sources.



Secret Broadcast Features Built In

ATEM Mini has an easy to use front panel, however it's also hiding very powerful broadcast features, allowing a true broadcast production workflow. If you are interested in a career in the television industry, then ATEM Mini is perfect for training as it has the same features as switchers in high end broadcast studios. You get a full ATEM Advanced Chroma Key, a Fairlight audio mixer, full DVE, still store for graphics and much more. Simply run the free ATEM Software Control app on Mac or Windows while connecting via USB or Ethernet to access the extended features of the ATEM Mini. With a little experimentation you can learn how to produce broadcast quality live production. Only ATEM Mini is a true broadcast switcher hidden in a tiny and affordable design.



Includes Free ATEM Software Control Panel

The ATEM Software Control app unlocks the hidden power of the ATEM Mini as you get total control over the switcher features, plus the software is included free for Mac and Windows. ATEM Software Control features a visual switcher user interface with parameter palettes for making quick adjustments. Although you can normally connect via USB, if you connect using Ethernet it's possible for multiple users to connect to ATEM Mini using separate copies of ATEM Software Control on different computers. The software lets you access full audio mixing with effects, load still frames and even advanced macro programming. You can save the switcher state as XML files. If you need clip playback, you can even control HyperDeck disk recorders via Ethernet.



DVE for Picture in Picture, Transitions and Effects

ATEM Mini features a full HD digital video effects processor, commonly referred to as a "DVE", that allows picture in picture effects and DVE transitions. The DVE lets you create professional picture in picture effects with customizable 3D borders, shadows and lighting. The image quality is the same as high end ATEM model switchers and the DVE supports position, resize and scale, all in real time. The DVE can also be used to create amazing transitions with 8 different DVE squeeze and DVE push effects for adding excitement to your programming. The DVE features a "fly key" so you can use it with custom graphics to create graphic wipe transitions.



Professional Broadcast Transitions

ATEM Mini includes a wide range of broadcast quality HD native transitions such as mix, dip, wipe and more. All transitions can be customized by adjusting parameters such as duration, border color, border width, position and direction. You can also use the DVE in transitions, allowing a graphic to be moved over the wipe edge which is called a graphic wipe, and is used in sports programming. To eliminate errors, ATEM Mini has a preview transition feature so you can check your transitions before putting them to air.



Built‑in Graphics with Photoshop Plug‑In

The built in "media pool" allows loading of up to 20 separate broadcast quality RGBA graphics for titles, opening plates and logos. A single media player is used to output the selected graphic so it appears as an extra internal video input, meaning you don’t have to waste any of the physical HDMI video inputs for graphics. You can even use still frames for complex effects such as graphic wipes. You can easily manage the still store graphic using the included ATEM Software Control app, or you can download directly from Photoshop software using the ATEM Photoshop plugin. ATEM Mini can even grab stills from the video output and add them to the internal media pool. The Photoshop Plug‑in is perfect for graphics that need to change often, such as scoreboards, as you can update the text and download directly into the switcher, allowing graphics to get on‑air fast.



Includes New ATEM Advanced Chroma Key

For news or on-set presentation work, ATEM Mini is the perfect choice as it features an ATEM Advanced Chroma Key for high quality chroma or luminance keying, plus an additional downstream linear keyer. The chroma keyer is incredibly powerful and features a color picker to sample background colors for automatic generation of the key parameters. You get precise controls for edge and flare, and there is even a foreground color corrector so you can match the "look" of the foreground layer to the background layer making seamless compositions possible. The keyer can also be used for pattern and DVE keying allowing incredible versatility. You can even use it for title overlays simply by using PowerPoint or other software with a green or blue background and the keyer will knock out the green and make the background transparent.



True Broadcast Style Mix Effects Switching

Although ATEM Mini works in "cut bus" mode when first purchased, it can also be changed to "mix effects" style operation, which is the most popular way large broadcasters use live production switchers. Cut bus switching is easy and selecting any input will instantly switch to that source. However if you want to operate ATEM Mini in a more professional way, then you can change the switcher to mix effects using the ATEM Software Control app. Mix effects operation allows a source to be selected but it won't be instantly put on air until you press the cut or auto buttons. That 2 step process means fewer mistakes because you can select the correct source before putting it to air. Mix effects operation means you can use any switcher in television stations as they work the same way.



Built In Professional Audio Mixer with 6 Band EQ, Compressor and Limiter

With a built in Fairlight audio mixer, the ATEM Mini makes it possible to do extremely complex live sound mixing. The internal mixer features a total of 12 channels so you get the ability to mix audio from all sources. 8 mixer channels are de-embedded from the HDMI inputs, while an extra two stereo audio channels are input via the 3.5mm microphone connections on the rear panel. Each input channel features the highest quality 6 band parametric EQ and compressor, limiter, expander and noise gate as well as full panning. You can even set up the software to auto mix between inputs as you switch "AFV" or to live mix multiple sources together all at once. All this audio power can be controlled via the ATEM Software Control app, or you can add a Mackie compatible panel or even a massive Fairlight Audio Console.



Automatically Convert HDMI Input Formats

You get 4 independent HDMI inputs, with each input featuring its own dedicated up and cross converter. That means ATEM Mini will automatically convert 1080p, 1080i and 720p sources to the video standard of the switcher. By default the switcher will set its video standard automatically, however you can also change the switcher to a specific video standard, to ensure compliance with local broadcast standards. The HDMI output is a true "aux" output so you can clean switch each of the 4 HDMI inputs or the program feed to this output. You can even "direct" switch input 1 to the HDMI output for low latency for eSport. If you select broadcast style mix effects switching, you can also output a preview feed, allowing verification of the source before transitioning to it.



Develop Custom Remote Control Solutions

The rear panel Ethernet connection allows incredible custom control solutions. Even though ATEM Mini includes the ATEM Software Control app, you can use the Ethernet to control the ATEM remotely, even from overseas. A popular workflow is to use the Ethernet to allow the ATEM Mini to be positioned near the HDMI cameras, but the control is positioned remotely in a quieter space, such as a control room. Imagine using the switcher from a control room and building a professional broadcasting studio where the control room can be separated away from the performance or interviews. Ethernet allows you to add as many panels as you like all at the same time, or you can build custom solutions using the developer SDK.



Upgrade to the Power of an ATEM Hardware Panel

With Ethernet built in, ATEM Mini can take advantage of the wide range of ATEM control panels, making possible high end workflows that take advantage of the hidden broadcast features in the switcher. ATEM hardware control panels feature a fast program/preview style which is the industry standard for switcher control. All transitions have direct access buttons and a t‑bar is included when performing manual blending of transitions. For accurate control of the DVE, a joystick provides X, Y positioning and rotate for DVE size. Then you can use the LCD menus to control features that don't have dedicated knobs and buttons. You can even set up and trigger Macros right from the panel. Upgrading the ATEM Mini with a professional control panel such as the ATEM 1 M/E Advanced Panel means you are able to use professional techniques and you'll never be limited creatively.

Specification

Input/Output
Inputs	4 x HDMI Type A 2 x 3.5 mm Stereo Analog Audio 1 x RJ45 Ethernet
Outputs	1 x HDMI 1 x USB Type-C (Computer/Webcam)
Video & Audio
Video Input Formats	HDMI Video: 1080p: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98 1080i: 60, 59.94, 50 720p: 60, 59.94, 50 HDMI Resolutions for Computers: 1080p: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98 1080i: 60, 59.94, 50 720p: 60, 59.94, 50
Video Output Formats	1080p: 60, 59.94, 50, 30, 29.97, 25, 24, 23.98
Video Sampling	4:2:2 YUV
Color Precision	10-Bit
Color Space	Rec. 709

Color Space Conversion	Hardware-Based, Real Time
Embedded Audio	-Channel Input and Output
Audio Mixer	6-Input, 2-Channel
Media Player	1 x Player with Fill and Key
Still Image Capacity	20
mage Format Support	PNG, TGA, BMP, GIF, JPEG, TIFF
General
Keyers	1 x Upstream 1 x Downstream 1 x Advanced Chroma 2 x Linear/Luma 1 x Transition (DVE Only)
Layers	Up to 4

Generators	1 x Pattern 2 x Color
DVE	1 x Border and Drop Shadow
Monitor Resolution	1366 x 768 or Greater
Number of Windows	10
Operating System Support	Apple macOS 10.13, 10.14, or Later Windows 10
Power Input	1 x Barrel
Voltage	12 V
Power Draw	18 W
Operating Temperature	41 to 104°F / 5 to 40°C
Storage Temperature	14 to 140°F / -10 to 60°

Relative Humidity	0 to 90% Non-Condensing
Dimensions	9.4 x 4.1 x 1.4" / 23.8 x 10.4 x 3.6 cm
Weight	19.4 oz / 550 g
Packaging Info
Package Weight	2.145 lb
Box Dimensions (LxWxH)	11.1 x 5.7 x 4.6"
-	-

In the Box

• Blackmagic Design ATEM Mini HDMI Live Stream Switcher
• Control Panel Software

Overview

Introducing the Cut Page

Designed specifically for editors working on high end fast turn around work such as television commercials and even news cutting, the cut page is all about speed. It’s an alternate edit page with a streamlined interface and revolutionary new tools that will help you work faster than ever. The cut page lets you import, edit, trim, add transitions, titles, automatically match colour, mix audio and more. Whether you’re delivering for broadcast or for YouTube, the cut page has everything you need to get the job done, all in one place. Plus, the regular edit page is still available so you can switch between edit and cut pages to change editing style right in the middle of a job.

• Dual Timeline - Revolutionary dual timeline lets you quickly navigate the whole edit and trim without wasting time zooming and scrolling.
• Source Tape - Quickly review all clips in a bin as if it was a single "tape" so you can select and add shots to the timeline without having to search a bin.
• Dedicated Trim Interface - The new trim interface in the viewer lets you see both sides of an edit and trim in frame accurate detail so you can create the perfect cut.
• Intelligent Edit Modes - To save time you don't have to place in points in the timeline as the edit modes can intelligently sync clips and edits for you.
• Fast Review - Quickly review an entire timeline or clips with variable speed playback that’s automatically set based on clip length.
• Transform, Retime and Stabilise - Built in tools for picture effects, retriming, stabilisation, dynamic zoom, text, audio and more, all in one place.
• Quick Export - Instantly render, upload and share your project to popular online services such as YouTube and Vimeo.
• Media Import - Quickly import individual files or entire directory structures with subfolders as bins into your project right from the Cut page.
• Portable Editing - The interface is scalable and works well on smaller laptop screens, giving you the highest amount of usable space.

Newly Developed Editing Features

DaVinci Resolve includes everything professional editors need to cut blockbuster films, television shows, and commercials. It’s perfect for both offline and online editing. The high performance playback engine makes editing and trimming incredibly fast, even for processor intensive formats such as H.264 and RAW.

• Custom Timeline Settings - Now you can create timelines with different frame rates, resolutions, monitoring and output settings in the same project.
• Adjustment Clips - Apply blend modes, transformations, ResolveFX, colour grades and more on top of a stack of clips in the timeline.
• Facial Recognition - Use the DaVinci Neural Engine to detect faces in your clips and automatically create bins based on the people in each shot.
• Speed Warp Retiming - Incredibly high quality motion estimation speed changes and frame rate conversions powered by the DaVinci Neural Engine.
• Image Stabilisation - Analyse shots and apply stabilization with full camera lock, zoom, smooth and strength controls right on the Edit page.
• Keyframe Curve Editor - Ease controls for position along with ResolveFX and OpenFX keyframes in the timeline curve editor makes animating effects faster.
• Tape Style Audio Scrubbing - High quality, tape style scrubbing with pitch correction makes it easier to understand dialogue while scrubbing.
• Faster, Smarter Encoding - Encode only the frames that have changed instead of re-encoding entire files for dramatically faster rendering when delivering.
• Frame.io Integration - Collaborate remotely by browsing Frame.io content, seeing comments and synchronizing annotations, all without leaving DaVinci Resolve.

Fusion VFX Features

With over 250 built in tools, Fusion VFX’s advanced 3D compositing engine and node based workflow let you quickly connect effects and tools together in a flow chart style, making it easy to create cinematic feature film quality visual effects and broadcast motion graphics right inside of DaVinci Resolve.

• Faster 3D Performance - Dramatically improved GPU accelerated performance for all 3D operations.
• GPU Accelerated Tools - Time effects, dissolves, stereo, vector motion, pinning, colour and more.
• Faster Masks - All mask operations are accelerated, including B‑Spline and bitmap masks.
• Improved Trackers - Greatly improved performance and accuracy in planar and camera trackers.
• Better Caching - Faster and more reliable playback when using smart cache and user cache.
• Better Memory Management - Makes working with large compositions with high tool counts more reliable.

Newly Developed Colour Features

DaVinci Resolve’s legendary colour tools let you manipulate colour in breathtaking ways to get results that are simply impossible on other systems. That’s why DaVinci Resolve has been used on more feature films and television shows than any other grading system. You get powerful primary and secondary tools, curves, tracking, stabilization and more.

• ResolveFX Keyframe Track - The Keyframe Editor now supports viewing and editing keyframes for both ResolveFX and OpenFX plugins, making it easier to create animations.
• GPU Accelerated Scopes - GPU accelerated scopes show more detail, have faster performance, and add dozens of new options for advanced technical monitoring.
• Curves with Histograms - Custom and HSL curves can display a histogram that lets you see which part of the curve affects the image to help guide your adjustments.
• Auto Colour Balance and Matching - The auto colour balance and auto shot match tools now use the DaVinci Neural Engine to process images for more accurate results.
• Gallery and Wipe Improvements - Gallery sort controls, hover scrub, match reference wipe, stills in split screen, and timeline wipe options make it easier to organize grades.
• Copy and Paste Attributes - Copy the colour grade, windows, tracking and plug in effects from one node, and paste only the attributes you want on to another node.
• Gang Viewer Zoom to SDI Output - Gang the Colour page viewer with the SDI or HDMI video output so zoomed images appear on both the user interface and your video output device.
• View Independent Channels - Independently view R, G, or B channels in the viewer to help evaluate images for noise, artifacts, or when manually colour matching.
• Improved OpenFX Compatibility - ResolveFX and OpenFX can request random frames from the GPU, making DaVinci Resolve compatible with more third party plugins than ever.

New Fairlight Features

With Fairlight in DaVinci Resolve, audio is no longer an afterthought in post production. You get a completely integrated and powerful digital audio workstation with full mixer, EQ and dynamics processing, sample level audio editing, ADR tools, sound library support, FairlightFX audio plugins and more.

New Collaboration Features

New Collaboration Features in DaVinci Resolve 16 Featuring a universal timeline, powerful database driven design, bin and clip locking, built in chat, timeline comparison tools and more, DaVinci Resolve Studio is the world’s only post production solution that lets different artists all work together on the same project at the same time.



Specification

System Requirements

Mac: macOS 10.13.6 High Sierra 16 GB RAM Recommended 32 GB RAM Recommended for Fusion Blackmagic Design Desktop Video Version 10.4.1 or Later CUDA Driver Version 418.105 NVIDIA Driver Version as Required by Your GPU RED Rocket-X Driver 2.1.34.0 and Firmware 1.4.22.18 or Later RED Rocket Driver 2.1.23.0 and Firmware 1.1.18.0 or Later Windows: Windows 10 Update 16 GB RAM Recommended 32 GB RAM Recommended for Fusion Blackmagic Design Desktop Video Version 10.4.1 or Later NVIDIA/AMD/Intel GPU Driver Version as Required by Your GPU RED Rocket-X Driver 2.1.34.0 and Firmware 1.4.22.18 or Later RED Rocket Driver 2.1.23.0 and Firmware 1.1.18.0 or Later Linux: CentOS 7.3 32 GB of System Memory Recommended Minimum Blackmagic Design Desktop Video version 10.4.1 or Later NVIDIA/AMD Driver version as Required by Your GPU RED Rocket-X Driver 2.1.34.0 and Firmware 1.4.22.18 or Later RED Rocket Driver 2.1.23.0 and Firmware 1.1.18.0 or Later

In the Box

• Blackmagic Design DaVinci Resolve 16 Studio (Activation Card)
• Activation Code

Overview

Featuring two large independent eight inch LCD screens in a compact rack mount design, Smart View Duo handles SD, HD and 3Gb/s SDI video standards. SmartView Duo is perfect for post production, broadcast and live event monitoring. For easy setup, all screens can be remotely adjusted via ethernet connection. With SmartView Duo you can install SDI monitoring everywhere you need!

Features:

• 3G/HD/SD-SDI Inputs, Both with Loop-Out
• Integrated Tally for Live Broadcast
• Ethernet Input for Adjustments
• Upgradeable Firmware via USB
• 2K, 1080i/p, 720p & 50/60 Hz SD Support
• 10-Bit Color & 4:2:2 / 4:4:4 Sampling
• 800 x 480 Resolution

SmartView is the affordable and compact SDI rack monitoring system perfect for post production, broadcast or live events. SmartView is available in two exciting ultra thin compact rack mount designs that are only an inch thick. SmartView Duo features two beautiful 8" LCD screens and for monitoring of multiple sources and the new SmartView HD with a large 17" LCD screen. Both SmartView models handle all SD, HD and 3 Gb/s SDI video formats and include built in ethernet so can be remotely adjusted from your Mac or PC. SmartView includes red, green and blue tally indications, perfect for the largest broadcast systems! With SmartView monitoring you can afford to put SDI monitoring everywhere you need it!

Monitor Everywhere!

Good quality SDI monitoring is expensive and often makes it hard to put monitoring on all the devices in your racks or control rooms because costs add up quickly. SmartView Duo eliminates this problem and includes two large, beautiful 8 inch displays in a compact 3 rack unit size! You get full loop though SDI connections and an ethernet network connection for setup. SmartView Duo includes easy to use software for Mac and Windows, so you can see all the monitors on your network for remote adjustments. That’s perfect when you want to color match all screens in a video wall remotely from your laptop! SmartView Duo even includes tally!

Perfect for Live Production

SmartView is perfectly designed for building a video wall for monitoring all sources into live production switchers, and because it’s so incredibly thin, it’s even perfect for portable setups where you need to save space. Imagine having all your video sources displayed on large 8 inch or 17 inch LCD screens so you can see camera focus and quality! Now you can build full live broadcast presentation monitoring that’s small enough to be fully portable! SmartView is lightweight and thin, so it’s perfect for outside broadcast vans or even installed into portable monitor racks to reduce shipping costs of flyway kits!

Take a closer look at SmartView Duo

SmartView Duo features two large 8 inch LCD screens in a compact rack mount design that's less than an inch thick! SmartVideo Duo handles all SD, HD and 3 Gb/s SDI video standards, and all screens can be remotely adjusted via your ethernet network!

Greater SDI Compatibility

SmartView Duo is designed to be used for broadcast as well as post production so it includes support for more SDI video standards, including SD, HD and 3 Gb/s SDI formats. SmartView Duo allows firmware updating so it’s easy to upgrade to new SDI video formats when they are invented, and updates are free from the Blackmagic Design web site. SmartView Duo includes new advanced video standards used in post production including 1080 progressive HD rates and even 2K SDI over 3 Gb/s SDI video. All video formats can be connected and changed, because SmartView Duo simply switches in less than a second to the new format!

Smart Ethernet Control

There’s nothing more complicated than trying to match all your monitors by climbing all over your equipment and using little screwdrivers! Simply connect your SmartView Duo to your Ethernet network and use the included Mac and Windows software to adjust all your monitors from one central location. The Monitor Utility software uses Bonjour to automatically find all the SmartView Duo monitors on your network. You can save monitor settings from one monitor and copy to another, and when you’re working with lots of monitors, SmartView Duo even includes an identify mode to help you find the monitor you’re adjusting! SmartView Duo won’t suffer from drift because all adjustments are fully digital.

International Power Supply

If you’re traveling all over the world, SmartView Duo is perfect because it includes a standard 12 volt power supply with socket adapters for each country. Ideal for live location use where you don’t have engineering support, a standard 12 volt power socket means you can get spare power supplies from any electrical store. To eliminate accidental unplugging of power cords during live production or at other crucial times, SmartView Duo includes a cable tie down point so everything is perfectly secure!

Integrated Tally

SmartView Duo includes full tally features so it’s the perfect companion for live broadcasters. Unlike a simple tally light, SmartView Duo includes tally borders that can be independently displayed in red, green or blue. Each screen features an independent tally in the three colors so you can signal to the user more than a simple on air status. Tally is connected via a standard parallel pin connector on the rear of SmartView Duo so you get full compatibility with any switcher or automation system.

Specification

Signal System	Digital signal support for both 50 Hz (PAL) and 60 Hz (NTSC) regions
SDI Input	Switchable (auto-selects) between SD, HD and 3 Gb/s SDI. Reclocked loop-through output
Multi-Rate Support	Auto detection of 2K, HD or standard definition inputs
SDI Format Support	525i59.94, 625i50, 720p50, 720p59.94, 720p60, 1080i50, 1080i59.94, 1080i60, 1080PsF23.98,1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080p23.98, 1080p24, 1080p25, 1080p29.97,1080p30, 1080p50, 1080p59.94, 1080p60, 2048x1080p/23.98, 2048x1080p/24, 2048x1080p/25, 2048x1080PsF/23.98, 2048x1080PsF/24, 2048x1080PsF/25, 2048x1556PsF/23.98, 2048x1556PsF/24, 2048x1556PsF/25
SDI Compliance	SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, and SMPTE 425M
Color Space	REC 601, REC 709
Video Sampling	4:2:2 and 4:4:4
Color Precision	10-bit
Monitor Type	TFT active-matrix LCD
Screen Size	2x 8" diagonal

Resolution	800 x 480
Display Colors	16.7 million colors
Viewing Angle	Not specified by manufacturer (displays can rotate upside down for optimal viewing angle)
Brightness	Not specified by manufacturer
Contrast Ratio	Typically 500:1
Response Time	< 15 ms
Inputs	2x SD/HD/3G-SDI (switchable, with auto-detection of HD/SD/2K sources) 1x USB 2.0 (480 Mb/s for updates and configuration) 1x 9-pin D-type (standard parallel connector for tally) 1x 10/100 BaseT Ethernet (for configuration)
Outputs	2x SD/HD/3G-SDI (loop-out) 1x 10/100 BaseT Ethernet (loop-out)
Platform	Mac OS X and Windows software control
Remote Control	No

Operating Temperature	Not specified by manufacturer
Power Requirements	12-15V
Power Consumption	< 20
Rack Space Height	3 RU
Dimensions (WxHxD)	48.3 x 13.3 x 2.5 cm
Weight	Not specified by manufacturer

In the Box

• BlackMagic Design SmartView Duo 2
• 12V Universal Power Supply with International Socket Adapters for All Countries

Overview

The Blackmagic Design H.264 Pro Recorder is designed for the industry professionals who require professional encoding from SDI, HDMI, analog/component composite, and balanced audio. The flexible Pro Recorder enables you to capture old or new video formats into the same file formats used on the web, iPad, iPod, iPhone, Apple TV, and more, providing a convenient solution to capture from professional broadcast decks directly to SD and HD H.264 files.
With the Media Express software, you can encode hours of content into popular online formats and batch H.264 files with an attractive user interface as well as create playlists from captured files. The software supports CMX EDL import and RS-422 accurate deck control, and is compatible with Mac and Windows operating systems. It also provides clip information such as frame size, frame-rate, color space, format, and codec.
The H.264 recorder allows you to capture high-quality videos and select between SDI, HDMI, and analog component video inputs. Apart from capturing audio from the SDI, HDMI, or stereo balanced analog audio input jacks, you can also connect the recorder directly to HD or SD video sources as the SDI, HDMI, and capture from HDCAM, Digital Betacam, Betacam SP, DVD players, and more. Analog video inputs switch between component s-video and composite, and support SD and HD.
The Pro Recorder allows you to save your old memories as digital files on your PC, converting old programming video formats into H.264 file format. It supports real-time scaling, and allows you to capture videos at full HD or SD resolution. You can also resize videos in real-time to scale and encode for playing on devices such as iPhone, iPad, or iPod. The adjustable tools can crop unwanted video portions such as black borders and VHS switching.

Real-time H.264 encoder that connects via USB

Designed for industry professionals who need professional encoding from SDI, HDMI, analog component/ composite and balanced audio

Capture from professional broadcast decks directly to SD and HD H.264 files

Capture old or new programming content into the same file format used on the web, iPad, iPod, iPhone, Apple TV, and YouTube

Media Express software to encode content into popular online formats

Batch H.264 files with a user interface

RS-422 deck control is included with software for Mac and Windows

Clip information - frame size, frame-rate, color space, format, and codec

Converts old video tapes to H.264 file format

Real-time scaling/cropping

Ideal for mobile applications using a notebook/computer (power supply required)

 Specifications

Connections	SDI Video Input: 1 x 12 bit SD/HD switchable. Analog Video Input: 1 x Component YUV on 3 BNCs switchable to S-Video or Composite. Component supports HD and SD. HDMI Video Input: 1 x HDMI type A connector. SDI Audio Input: 2 Channels from embedded SDI audio. Analog Audio Input: 2 Channels of professional balanced analog audio with standard 1/4 inch jack connections. HDMI Audio Input: 2 Channels from embedded HDMI audio. Device Control: Sony compatible RS422 deck control port. Computer Interface: USB 2.0 high speed (480Mb/s)
Standards	HD Format Support: 720p50, 720p59.94, 720p60, 1080PsF23.98, 1080p23.98, 1080PsF24, 1080p24, 1080PsF25, 1080p25, 1080PsF29.97, 1080p29.97, 1080PsF30, 1080p30, 1080i50, 1080p50, 1080i59.94, 1080p59.94, 1080i60, and 1080p60. SD Format Support: 625/25 PAL, 525/29.97 NTSC and 480p. SDI Compliance: SMPTE 259M and 292. Multiple Rate support: SDI, HDMI and component analog video connections are switchable between standard definition and high definition. SDI switches between 270 Mb/s standard definition SDI, 1.5 Gb/s HD-SDI and 3 Gb/s HD-SDI. Video Sampling: 4:2:2 Color Precision: 12 bit Color Space: 4:2:2 YUV Audio Sampling: Television standard sample rate of 48 kHz and 24 bit. HDMI Color Precision: 12 bit Copy Protection: For legal reasons HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content.
Processing	Encoding: Hardware based real time H.264 encoder supports multiple profiles for small, portable video devices through to full resolution HDTV. Real-time Scaling: Capture at full HD or SD resolution, or use direct resize in real-time to scale and encode for the intended playback device, such as iPhone, iPad or iPod. Real-time Cropping: Adjustable tools provide real-time cropping of unwanted video artifacts such as black borders and VHS switching.
Firmware	Firmware upgrade via USB.
Installation	Connect unit to the computer's USB 2.0 port, install Blackmagic H.264 Pro Recorder software and run Media Express.
-
PACKAGING INFO
Package Weight	1.3 lb.
Box Dimensions (LxWxH)	6.2 x 5.4 x 2.6"

Overview

The Mini Converter SDI Distribution 4K from Blackmagic Design allows you to distribute a Single Link SD/HD/3G/6G-SDI signal to eight SDI devices simultaneously. It automatically detects the input signal type, re-clocks it, and its eight outputs automatically match the SDI input video format. With a compact form factor and easy-to-use controls, the Mini Converter is ideal for a variety of broadcast, post production, and professional AV applications.

Using 6G-SDI technology, the Mini Converter supports resolutions up to Ultra HD 4K (3840 x 2160) at up to 30 fps and DCI 4K (4096 x 2160) at 24 fps, as well as SD, HD, and 3G-SDI signals. It supports all SDI-related transmission features, including embedded audio, ancillary data, and even handles ASI signals - asynchronous signals that carry multiple compressed programs that can be at varying transmission speeds. The Mini Converter's settings are controlled using the built-in DIP switches or via USB using the included software for Max OS X or Windows computers. The USB port also enables the firmware to be updated. For powering the device, a 12V power supply is included with international socket adapters.

Additional Features

• 4:2:2 and 4:4:4 sampling and color precision
• 24-bit, 48 kHz audio sampling
• Compliant with SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, and SMPTE 425M standards

Specifications

Video Input	1 x 6G-SDI
Video Output	8 x 6G-SDI
Multi-Rate Support	Auto detection of SD, HD, or 6G SDI signals
Reclocking	Yes
Format Support	SD: NTSC 525/29.97 and 525/23.98 PAL 625/25 HD: 720p 59.94/60 1080i 50/59.94/60 1080PsF 23.98/24/25/29.97/30 1080p 23.98/24/25/29.97/30/50/59.94/60 2K: 2048x1080PsF 23.98/24/25 2048/1080p 23.98/24/25 UHD/4K 3840x2160p 23.98/24/25/29.97/30 4096x2160p 24
SDI Compliance	SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, and SMPTE 425M
SDI Video Rates	Switchable between SD, HD, and 6G SDI
SDI Video Sampling	4:2:2 and 4:4:4
SDI Audio Sampling	24-bit, 48 kHz
SDI Color Precision	4:2:2 and 4:4:4
SDI Color Space	YUV and RGB
SDI Auto Switching	Automatically detects SD, HD, or 6G-SDI
ASI Support	Yes
Settings Control	DIP switches or USB software for Mac PS X and Windows
Firmware Upgradeable	Via USB 2.0
Power Supply	12 VDC
Power Consumption	4.8 W
Operational Voltage Range	12 to 30 VDC
Operating Temperature	32 to 104° F (0 to 40 ° C)
Storage Temperature	-4 to 113° F (-20 to 45 ° C)
Relative Humidity	0 to 90% non-condensing
Dimensions	4.80 x 3.63 x 0.90" (12.19 x 9.22 x 2.29 cm)
Weight	11.88 oz (336.79 g)
